Similar Topics
-
By CSM_Retired
View File Kioti Daedong K9 2400 Shop Manual
This manual is to provide servicing personnel with information on the general speci- fications, service, operating principle, troubleshooting, exploded view including part name, removing and installing procedures for K9 2400/K9 2440 UTV (Utility Vehicle) with high-end technology.
All information in this manual is based on the latest product information available at the time of publication. Therefore, some of the information in this manual may differ from the machine you have.
KIOTI has a principle to apply update to the next edition of the manual if there is any. However, KIOTI has no obligation to modify the contents in this manual, especially the contents in the manual which is already distributed or published.
The modified information is available in KIOTI's online electronic manual system (DEMSS).
This manual is ultimately to satisfy customers with best performance of this UTV. If there is any typo, wrong information or question for this manual, feel free to contact KIOTI.
Submitter CSM_Retired Submitted 01/02/2025 Category KIOTI
-
By BMurph
Hello everyone! I am new here and have no experience with UTVs but I am quickly getting some. I have a shifting problem where I can shift through all gears without the engine running but as soon as I start the engine I can not select a gear. Yes, foot is on the brake and yes the pin is being pulled to go into reverse if I was to try going into reverse. The shift lever does not move. I adjusted the linkage to get more accurate shifting with the engine off so I know those are now correct. I opened the shift lever housing to inspect the teeth on the gear and found this picture below. Why is this oil so milky looking? I assume with oil like this I'll need to replace the wet clutch as well but am not positive. Does anyone have any input into how to flush this system and get things shifting correctly? Thanks in advance for all the help!
-
By BMurph
Hi everyone. I am new here to the forum and am excited to learn from all of you with more experience than me with UTVs. Our Axis750 we use on the hobby farm started to have some issues going into gear. Yes, foot is on the brake and completely stopped as required with these machines. I thought it was the linkage and adjusted it to where it is accurately shifting with the engine off and key in the on position. I start the engine and it won't shift gears (yes foot is on the brake). I thought maybe it was the shift lever teeth so I opened the assembly and this picture shows what I just found. I assume this means the wet clutch would need replaced too while draining and flushing the oil. What else should I consider or be looking at? Any idea what could cause this? I don't see visible leaks or cracks in the system anywhere. Thanks in advance for the help!
-
By didgeridoo
Hello, All! I've decided to replace the traction batteries in my 2018 Sector E1 with a 48V Lithium set. They may be expensive, but I figure the Discovery Dry Cell are, too. I am not looking for the max driving range, as I have never received near the brochured range to begin with, but a good mix of charge/ get work done/ charge is what I am expecting.
I have settled on the 48V EAGL kit from bigbattery dot com. Each battery pack provides 30Ah. The kit ships with a charger, as well. The packs would be physically connected in parallel (using a busbar) to one another, maintaining the 48V voltage, but together would be able to provide the amp draw the buggy pulls when going up hill or towing a rake (rated 320 max continuous Amps). This is in comparison to the serial connection the eight 6V lead batteries. Each of the EAGL batteries looks to have its own BMS; am I correct in thinking I will have to use their included charger rather than (simply) changing the onboard charger to lithium mode? The chemistry of the pack is LiFe PO4, for what it's worth. I haven't torn anything apart yet (to diagram), so I am not sure how the dash will interpret the AMP draw, but the kit I am looking at includes a dash mounted charge indicator.
If anyone has completed a similar conversion, do you have any tips? Specifically, how did you remove the original batteries, and how did you secure the new ones? I am guessing that almost any change from the stock batteries would involve at least some modifications. Any tips would be appreciated, especially things I may have failed to consider. Thanks!
-
By Brent C
Hi all, I own two Axis UTV's. Last year I purchased a 2022 Axis 500. I had a mechanical issue with the shifting forks after only 50 miles. I contacted Axis/Hisun warranty dept. That were very helpful and willing to send out a representative to see if it was a warranty issue that fell under coverage. Since I live in an area that does not have authorized repair facility within 300 miles. A really nice guy drove all the way from West Virginia which was 4 hours away. He determined that the console would not stay seated in position and while driving it, the console would jump forward and knock it into the wrong gear causing the shift forks to become bent. It was then picked up a few weeks latter to be repaired in Richmond, Virginia. It should arrive home soon.
Now to my question. After the 2022 Axis 500 was taken for repairs, I bought the 2024 550 Axis. I bought the first one to take my son who is disabled from an extremely rare disorder that requires daily care to get out of the house. There are two things that give him joy, music and going for rides. That is why I purchased the first one, However because it had bucket seats and the engine was between the two and was too loud even though I deaden the sound and put a quiet muffler on it.
I then decided to purchase the Axis 550 for the great updated features and the bench seat, I will be buying the complete enclosure ad on's offered by Hisun. Since it does not come with a heater (Axis 750 does) I was wondering if anyone knows what heater is part of the 750 edition. There was a photo that showed a Firestorm brand, however I can not find what variation it is. If anyone knows what a Inferno heater would be correct for the Axis 550. I would like to install it this Winter to take Justin riding on the farm. Any help would be greatly appreciated. Brent
-
